ECO CTE Evaporator 4.0 mm

The CTE 4.0 fin spacing range of unit coolers is suitable for installation in cold rooms for the preservation of fresh or frozen products. The compact size of the unit allows to make maximum use of the storage space of the cold room in which it is installed.

The entire range is equipped with high efficency coils madre from special profile aluminium fins and inner grooved copper tube, suitable for new generation refrigerants.

Thermofrost Cryo is an official ECO evaporators distributor in the UK.

Documentation	CODE	MODEL	Capacity KW(1)	Capacity KW(2)	Fans	Air throw (m)	List Price
-	ECO700	CTE 501E4	12.6	10.3	1	27	£3,212.00
-	ECO710	CTE 501A4	16	13	1	26	£3,771.00
-	ECO720	CTE 501B4	18	14.6	1	25	£4,380.00
-	ECO730	CTE 502E4	26.4	21.5	2	29	£5,259.00
-	ECO740	CTE 502A4	31.6	25.7	2	28	£6,303.00
-	ECO750	CTE 502B4	35.3	28.8	2	27	£7,339.00
-	ECO760	CTE 503E4	38.7	31.5	3	29	£7,477.00
-	ECO770	CTE 503A4	48.7	39.6	3	28	£9,050.00
-	ECO780	CTE 503B4	55	45	3	27	£10,530.00
-	ECO790	CTE 504A4	60	48	4	29	£11,623.00
-	ECO800	CTE 504B4	68	55	4	28	£13,688.00
-	ECO810	CTE 631E4	27	22	1	29	£6,328.00
-	ECO820	CTE 631A4	34	27	1	29	£7,432.00
-	ECO830	CTE 631B4	38.6	31.4	1	27	£8,613.00
-	ECO840	CTE 632E4	52.9	43.1	2	33	£10,321.00
-	ECO850	CTE 632A4	68	55.4	2	32	£12,463.00
-	ECO860	CTE 632B4	72.4	59	2	31	£14,084.00
-	ECO870	CTE 633E4	80	65.1	3	35	£14,934.00
-	ECO880	CTE 633A4	101.8	82.9	3	34	£18,257.00
-	ECO890	CTE 633B4	117.1	95.4	3	33	£21,169.00
-	ECO900	CTE 634E4	112.1	91.3	4	37	£19,860.00
-	ECO910	CTE 634A4	124.3	101.2	4	36	£23,573.00
-	ECO920	CTE 634B4	145.7	118.7	4	35	£27,790.00

ECO CTE Evaporator 4.0 mm
